Philips Uni Wall Mount Recessed
The Philips Uni Wall Mount recessed fixture is designed to provide functional and architectural lighting for outdoor spaces. Integrating the fixture into the wall creates a clean and unobtrusive light pattern, making it suitable for both modern new-construction projects and renovations.
This model delivers a luminous flux of 580 lumens at a power consumption of 12 watts. The warm white light color of 3000 K makes the fixture suitable for locations where functional lighting needs to be combined with a pleasant ambiance.
Sturdy LED outdoor wall fixture
The housing is made of cast aluminum and features a flat diffuser made of tempered glass. Thanks to its IP65 protection rating, the fixture is dustproof and protected against water jets.
In addition, the Philips Uni Wall Mount has an IK08 rating. This makes the fixture resistant to mechanical stress and suitable for use in public and semi-public environments.
Applications
The Philips Uni Wall Mount recessed fixture can be used in the following applications, among others:
- entrances and access points;
- walkways and sidewalks;
- parking lots and parking garages;
- parks and squares;
- outdoor terraces;
- garden walls and retaining walls;
- public and commercial outdoor spaces.
Thanks to its integrated wall-mount design, the Uni Wall Mount is particularly well-suited for projects in which functional wayfinding lighting needs to be an integral part of the architecture.
Technical Specifications
| Specifications | Value |
|---|
| Manufacturer | Philips |
| Series | Uni Wall Mount Recessed |
| Type | BWP400 LED WW 220V 12W WB PSU 7012 |
| Technology | LED |
| Assets | 12 W |
| Luminous flux | 580 lm |
| Light output | 48 lm/W |
| Color Temperature | 3,000 K |
| Light Color | 730 warm white |
| Color Rendering Index (CRI) | 70 |
| Input Voltage | 220–240 V |
| Frequency | 50/60 Hz |
| Labor factor | 0,9 |
| Dimmable | No |
| Driver included | Yes |
| Protection Class | IP65 |
| Impact Resistance | IK08 |
| IEC class | Class I |
| Housing Material | Cast aluminum |
| Light Cover Material | Tempered glass |
| Housing Color | Gray |
| Dimensions | 205 × 107 × 71 mm |
| Weight | 0.89 kg |
| Ambient Temperature | -40 °C to +50 °C |
| Warranty | 3 years |
| EAN | 6923828611026 |
| Part Number / 12NC | 911401698508 |
Professional wall lighting from Philips
The combination of a compact recessed design, robust construction, and warm white light color makes the Philips Uni Wall Mount a practical solution for professional outdoor projects. The fixture can be used as wayfinding lighting along paths and entrances, as well as an architectural lighting element on facades and walls.
Do you need help determining the right number of fixtures or the best application for your project? Contact LED Goeroe for advice or request a quote right away.
